RRFBs
AV-400 RRFB
Rectangular Rapid Flashing Beacon
Purpose built from the ground up, the AV-400 has raised the bar for RRFBs.
Every aspect of the design from the controller to the mounting brackets incorporate features to minimize installation time and expense.
High efficiency LED modules and an ultra-low power purpose-built controller deliver dependable year-after-year operation.
Specifications
Operational
Dual (back-to-back) or single lightbar configuration
MUTCD compliant
WW + S (wig-wag plus simultaneous) flash pattern
Exceeds SAE J595 Class 1 specifications
Automatic night dimming
Meets SAE J578 chromaticity specifications
Field adjustable flash duration, channel, night intensity
Capacity: Exceeds 300, 20 second activations per day
System
20W high efficiency monocrystalline solar panel
45º tilt angle, 360º rotation
12V 14-18Ah battery capacity, AGM sealed lead acid
Ultra low-power controller with integrated processor, Maximum Power Point Tracking (MPPT) charger, wireless module, and field configuration
2.4 GHz wireless mesh network, 10 channel, 1000’ range
Synchronized wireless activation under 150ms
Weight (including mount and batteries): 19.1lbs
Installation
Pre-wired post-top solar engine assembly
Hinged solar panel for easy front access to install batteries
Quick connect battery connections
Simple two wire run; one wire to the lightbars and one wire to the push button
Quick connect wire terminal at lightbar
Activation
Compatible with: Polara BDSP-014 BullDog III, Campbell 4 EVR MOAB, and Polara iNX / iDX Push Button Station
Pole Mount
Universal pole mount for solar engine and lightbar, compatible with 2”, 2 1⁄4”, 2 1⁄2” square telespar, 2 3⁄8” – 4 1⁄2” round pole
Side of pole mount option
Environmental
System operating temperature: -40 to 165° F (-40 to 74° C)
Battery operating temperature: -40 to 140° F (-40 to 60° C)
Compliant to NEMA TS 2, Sections 2.2.7, 2.2.8, and 2.2.9 for temperature/humidity, vibration, and shock
